The control system employs a human-machine interface touchscreen, making operation simple and including a fault display system for easier maintenance.
Pneumatic components utilize standard Taiwanese-made parts, ensuring high functionality and low failure rate for superior machine performance.
The transmission system uses Taiwanese-made bearings and shafts, offering wear resistance and a long service life.
The printing method features a servo motor-driven system, ensuring precise color registration, smooth printing, and reduced printing defect rates.
The photoelectric automatic alignment system: For containers without a fixed position, printing two-color sets is challenging. Visual inspection can be inaccurate due to angle variations. This machine uses an image sensor paired with a servo motor to quickly rotate the container to the correct printing position. The photoelectric system automatically grips the correct position, eliminating the need for manual alignment.
| Mode | WE-500C1 |
| Pringing color | 1 |
| Operation interface | membrane switch or HMI |
| Max, frame size | 680*450 |
| Max printing area | 200 x 400 φ120 |
| Screen vertical adjustable range | 110 |
| Table vertical stroke | 150 |
| Max. printing stroke | 500 |
| Capacity pre hour | 600 ~ 1,800 |
| Machine Dimensions | 950 x 950 x 1,650 (mm) |
| Net weight (kg) | 215 kg |
| Print Head width | 90 |
| Print head vertical stroke | x |
| squeegee vertical stroke | 50 |
| effictive length of rack | 600 |
| Print head center distance | 175 |
| Steel table dimensions | L600*W680*H630mm |
| Screen vertical shaft diameter | ∮40mm |
| Input power | Single phase AC110V or 220V 5A 50~60Hz |
| Air source | 6kg/cm2 |
| Control panel height from floor | 650 |
| Jig center height from floor (lowered position) | fixed 920mm |
