Product Features
- Efficient Workflow
- Manual loading → Indexing table rotates to the printing area → Automatic printing → Manual unloading.
- Supports independent single-color printing for dual objects (suitable for symmetrical items).
- Structural Optimization
- Reciprocating Plate Design: Features a reciprocating steel plate mechanism with a center-mounted motorized ink-cleaning device.
- Load Reduction Technology: The fixed-plate configuration reduces the burden on the pushing cylinders, ensuring long-term positioning stability and high precision.
- Independent Dual Cylinders: Equipped with two independent cylinders (∮50*125mm) with a 160mm center distance, enabling high-efficiency synchronized printing.
- Patented & Core Components
- Eco-friendly Tungsten Steel Ink Cup: Utilizes imported tungsten steel ink cups that save ink and solvents while being easy to clean. The odor-free design ensures uniform color and meets environmental standards.
- Patented Scraping Mechanism: Ensures stable, smooth, and clean ink scraping.
- Premium Pneumatic Components: Uses high-quality Taiwan-made pneumatic parts to ensure stable performance and increased production capacity.
- Advanced PLC & HMI Control
- Equipped with a PLC and Human-Machine Interface (HMI) for more convenient operation and maintenance.
- Highly Customizable Settings:
- Programmable settings for four sets of dwell times and print counts (0–99 seconds).
- Supports manual, semi-automatic, and fully automatic modes.
- Customizable pre-printing or post-inking sequences (0–9 times).
- Quality Control & Safety
- Automatic Pad Cleaning: Built-in pad cleaning device (100mm tape) automatically removes residual ink and dust from the pads, significantly improving yield rates.
- Safety Protection: Both sides are equipped with manual sliding acrylic safety shields.
- Integrated Inspection Lighting: Widened stainless steel lamp holders and built-in lighting allow operators to monitor printing quality in real-time.
Specifications
| Model | WE-262STC | WE-262STC-CL |
 |  | |
| Color | 2 | 2 |
| Ink supply | Ink-cup ∮90mm (sealed) | Ink-cup ∮90mm (sealed) |
| Control panel | Membrane switch(HMI panel optional) | Membrane switch(HMI panel optional) |
| Steel plate size(mm) | 120*250*10 | 120*250*10 |
| Max print area | ∮75 | ∮75 |
| Pad front-rear stroke (mm) | 200 | 200 |
| Pad up-down stroke (mm) | 80 | 80 |
| Slide table stroke | ✖ | ✖ |
| Positioning accuracy | (+/-0.02) | (+/-0.02) |
| Working table size (mm) | ∮800mm | ∮800mm |
| Working table up-down | Fixed | Fixed |
| Rotary table | 8 stations (customizable) | 8 stations (customizable) |
| Hot air dryer | ✔ | ✔ |
| Ink removal device | ✔ | ✔ |
| lighting device | ✔ | ✔ |
| Unloading robotic arm | Optional | Optional |
| Output/Hr | 900-1200 | 900-1200 |
| power d(choose one) (5A for hot air device) | 1Phase 220V 5A 50~60Hz | 1Phase220V 5A 50~60Hz |
| input Air pressure (kg/cm2) | 6 | 6 |
| Pad pressurize kgf | 186 | 186 |
| Air consumption (L/Min) | 30 | 30 |
| Dimension L*W*H (mm) | 1510 * 900 * 1750 (mm) | 1510 * 1100 * 1750 (mm) |
| Net WT(kg) | 450 | 480 |
| CE certification option | Optional | Optional |
| Cleaning device | ✖ | ✔ |
