Vacuum degassing ink mixer

WE-5RA

Vacuum degassing ink mixer

Non-contact ink mixing, vibration stirring and vacuuming

WE-5RA

Applicable for

Ink coating, conductive gold, silver paste, carbon ink, window glue, solder mask green paint, gold powder, silver powder, matte powder and all liquid materials to be mixed.

Most suitable for UV ink, because UV ink contains SILICON and is not easy to stir.

Add to inquiry list
Inquiry Form

Product Features

1. No bubbles will be generated after the ink is stirred.
2. There is no need to clean the traditional blade mixer after use, so the workplace is kept clean.
3. The new vacuum ink mixer has an ink temperature window, which can clearly show the current temperature of the stirred ink. If the machine is over-vacuumed, the ink will also be notified through this window, so that the ink will not be directly sucked into the vacuum pump, ensuring the life of the vacuum pump.
4. The new vacuum ink mixer is equipped with a safety micro switch. If the ink tank pops out during mixing, the mixer will automatically cut off the motor power supply and stop oscillation.
5. After starting, the vacuum meter will show whether the ink tank has reached the vacuum standard, so that the user can better understand the mixing situation.
6. The mixing is completed within 6-10 minutes, and the maximum viscosity of the ink can reach 400,000c.p.s.
7. The pneumatic ink mixer adopts a toothless design, so there is no need to worry about the tooth row breaking.
8. When the upper pressure plate of the machine does not reach the position (the upper pressure plate does not clamp the fixture tank), the machine will automatically detect and stop stirring immediately to ensure the safety of the operator
9. Two-point combination, when the upper pressure plate is not clamped tightly, the pressure of the upper pressure plate can be adjusted.
10. Simple operation, only one button is needed to complete the action of fixing the fixture tank.
11. The ink tank is fixed by a pneumatic cylinder, and there is no need to replace the fixing handle regularly.
12. This machine uses German FESTO pneumatic components with excellent quality.
