Including pad printing machines, screen printing machines, automatic printing machines, heat transfer machines,
flame treatment machines, UV drying equipment, as well as plate-making equipment, ovens, and infrared dryers.
Product Specification
Roller Size Hardness | ID38*OD100*L200mm 70°,80°,90° |
---|---|
Stroke | 60mm |
Heat Tube | ∮14*L300mm 130V/600W*6pcs |
Tempareture | 0~400℃ |
Working Table | 220*420mm, Height:900mm |
Width Of Foil Feeder | 260mm |
Beam SenSor | Keyence (FS-N11N) |
Foil Tension Controller | OPC-10(Ogura, Japan)-optional |
Dimension | 70*110*188cm |
Net Weight | 300kg |
