Single color ink cup pad printer(WE-261ST) - Guger Industries Co., Ltd.

Steel plate forward/backward movement device, with motor type pad clean device. Steel plate is fixed.
Steel plate forward/backward movement device is designed for good registration with low loading for long term operation.
Add the acrylic shield (manual slide shuttle) and fluorescent lamp in both sides of the machine.
PLC control can set the printing times, pause time 0-99 seconds, printing q'ty, manual/auto mode, printing in front/back side:0-9 times.
Add one set pad clean device for cleaning the surplus ink or dust on pad for increasing printing quality and yield rate. (tape 100mm)
6Kg air pressure is enough for this machine, have the break time for air compressor and save the electric power and extend the life of the air compressor.
Using imported tungsten ink cup for stable quality, save the cost of ink & solvent, no scent, no smell, beauty printing color, low pollution and increase the production capacity.
The extra light mounted on the machine give clear printing.
Patent ink squeegee device provides stable, smooth, clear ink squeezing.
The hot air device is necessary for the dry and pad clean after printing.
The hot air device includes 1/4HP motor, 2Pcs heater, LCD display temperature gauge, two blow tubes, two set adjustable holders.
